Kubectl Workflow

A Kubectl workflow provides a direct way to interact with a Kubernetes cluster, allowing teams to manage resources, deploy applications, and troubleshoot issues using kubectl commands.

For example, when scaling an application or deploying a new version, a Kubectl workflow would execute the necessary kubectl commands to update the deployment, manage services, or monitor the status of resources in the cluster.

Create a Kubernetes Workflow​

Subscribe and use StackGuardian's kubernetes-template. This template provides a pre-configured environment for managing Kubernetes clusters with tools like kubectl and Helm.

Following this guide, let's configure a Kubernetes workflow.

  1. Navigate into the Workflow Group, click Create Workflow and choose "Use Wizard" > "Custom".

  2. StackGuardian provides two options:

  • Enable VCS settings to connect your code from the Git repository by providing the URL, then click "Next".
  • Or simply, click "Next" to proceed without it.

  1. To create an apply action (used to apply Kubernetes manifests), click on "Add New Step" and configure it as follows:

    • Step Name: Enter a relevant name, such as "apply-manifest".
    • Workflow Step Template: Select /stackguardian/kubernetes.
    • Workflow Step Template Revision: Choose the latest, e.g., kubernetes:4.
    • Command Override: Leave blank unless customization is needed.
    • Kubectl Version: Choose the latest version. 1.26.0
    • Namespace: Set to default or specify a custom namespace.
    • Select Executable: Choose kubectl.
    • Kubectl Action: Select apply (other options include get to retrieve resources, and delete to remove resources).
    • Run with --dry-run: Check this if you want to simulate the action without actually executing it.
    • Additional Parameters: Optional; used for referencing output or vault secrets from other workflows.

  2. After configuring the step, click Next to fill in the workflow metadata. Finally, click Next to launch the workflow.

Fig: Kubernetes workflow type

Using this setup, you can create and manage Kubernetes workflows for applying manifests, retrieving resources, and deleting them as needed. You can also create a workflow step to delete or get resources based on your specific requirements.

Dive into Workflow​

StackGuardian workflows provide multiple tabs for monitoring, managing, and refining your deployments. Each tab offers specific insights and actions to optimize your workflow experience.

Overview​

The Overview tab highlights key workflow details, including compliance check results, cost estimations, and resource summaries like drift detection and schedules. It offers a quick snapshot of your workflow's status.
Learn more in the Workflow Overview Guide.

Runs​

The Runs tab lists all executions with real-time status, unique run IDs, and metadata, such as user actions and modification timestamps. Click a Run ID to view detailed logs and execution progress.
Explore the Workflow Runs Guide.

Outputs​

The Outputs tab displays execution results and downloadable artifacts like tfstate.json. Use key-value pairs to reference outputs in other workflows, making your infrastructure provisioning more dynamic.
See the Workflow Outputs Guide.

Settings​

The Settings tab enables post-creation updates, such as modifying input variables, refining Terraform runtime settings, reordering custom steps, or managing cloud connectors and environment variables.
Learn more in the Workflow Settings Guide.
